Transfer / Surface
General Description
The NEA Line is built to the most demanding quality standards, combining different materials according to the requirements of each application.
Designed specifically under API standards, these pumps are prepared to withstand continuous and demanding work in oilfields (Upstream) and crude oil treatment plants.
API Standards
Continuous Duty
High Flow
Heavy Duty
Technical Specifications
| Max Flow Rate | Up to 400 m³/h |
|---|---|
| Max Pressure | Up to 48 bar |
| Max Temperature | 150° C |
| Max Viscosity | Up to 1,000,000 cP |
| Rotor Materials | 316 Stainless Steel / Chromed Alloy Steels |
| Available Stators | Nitrile, EPDM, Viton (High chemical resistance) |
| Main Application | Transfer and Surface (Upstream) |
- Crude Oil Transfer.
- Produced Water Injection.
- Truck Loading and Unloading.
- Polymer Pumping.
For specific dimensional details and performance curves, please download the PDF data sheet or contact engineering.
Why choose the NEA Line?
API Standard: Complies with stringent oil industry regulations.
Robustness: Ideal for harsh environments and abrasive fluids.
Versatility: Handling of high-viscosity fluids and solids.
